Hastelloy B-3 has excellent corrosion resistance to hydrochloric acid of all concentrations and temperatures, and also has effective resistance to reducing environments such as sulfuric acid, phosphoric acid, formic acid, acetic acid and other non-oxidizing media. It also resists pitting corrosion, stress corrosion cracking, edge and weld heat affected zone corrosion. Hastelloy B-3 has better thermal stability than B-2

product	ASTM
Rod	B 335
Plate, sheet and strip	B 333, B 906
Seamless pipes and fittings	B 622
Welded nominal pipe	B 619, B 775
welded pipe	B 626, B 751
Welded pipe fittings	В 366
Forged or rolled pipe flanges and forged fittings	B 462
Blanks and bar blanks for forging	B 472
Forgings	B 564

chemical composition

Element	Ni	Mo	Ni+Mo	Cr	Fe	W	Co
Smallest	65.0	27.0	94.0	1.0	1.0	-	-
Maximum	-	32.0	98.0	3.0	3.0	3.0	3.0

Element	C	Mn	Si	P	S	AI	Ti
Smallest	-	-	-	-	-	-	-
Maximum	0.010	3.0	0.10	0.030	0.010	0.50	0.20

Element	Cu	Nb	Ta	V	Zr
Smallest	-	-	-	-	-
Maximum	0.20	0.20	0.20	0.20	0.10

Physical properties

Density: 9.22 g/cm3

Melting point: 1370-1418℃

characteristic:

Hastelloy B-3 has excellent corrosion resistance to hydrochloric acid of all concentrations and temperatures, and also has effective resistance to reducing environments such as sulfuric acid, phosphoric acid, formic acid, acetic acid and other non-oxidizing media. It also resists pitting corrosion, stress corrosion cracking, edge and weld heat affected zone corrosion. Hastelloy B-3 has better thermal stability than B-2.

application:

Hastelloy B-3 has the same application fields as B-2, but like B and B-2, Hastelloy B-3 is extremely susceptible to corrosion in oxidizing environments and therefore cannot be used in environments containing iron salts or copper salts because these Substances can quickly cause corrosion.
