Incoloy A-286(S66286) iron-based deformed high-temperature alloy

US grade:Incoloy A-286/A286/UNSS66286/P.QA286

French brand: ZbNCT25

Incoloy A-286 Overview

Incoloy A-286 is a Fe-25Ni-15Cr-based high-temperature alloy, which is comprehensively strengthened by adding platinum, aluminum, vanadium and trace amounts of boron. It has high yield strength, durability and creep strength below 650°C, and has good processing plasticity and satisfactory welding performance. It is suitable for manufacturing high-temperature load-bearing parts of aeroengines that operate below 650°C for a long time, such as turbine discs, press discs, rotor blades and fasteners, etc. This alloy can produce deformed products of various shapes, such as discs, forgings, plates, rods, wires and ring parts, etc.

High-quality Incoloy A-286 alloy is developed on the basis of Incoloy A-286 alloy. As long as the purity of the alloy is improved, the gas content is limited, the content of low melting point elements is controlled, and the heat treatment system is adjusted, the thermal strength of the alloy and Improved performance over long term use. Incoloy A-286 Material grade Incoloy A-286

Incoloy A-286 similar grades A286, UNSS66286 (USA), ZbNCT25 (France), P.QA286 (USA)

Technical standards of Incoloy A-286 material Incoloy A-286 chemical composition Incoloy A-286 alloy chemical composition (Table 1), high-quality Incoloy A-286 alloy chemical composition (Table 2)

Table I

Note: 1. The standard for cold drawn rods, round cakes and ring damage stipulates w (Ti) 1.80%~2.35%

2. Hot-rolled and cold-rolled plate standards stipulate that w(B)0.003%~0.010%, w(Mn)<2.00%, w(P)0.020%, w(S)0.015%.

3. Cold drawn welding wire standards stipulate that w (A) 0.35%, w (Ti) 1.75% ~ 2.35%, w (Si) 0.40% ~ 1.00%, wP) 0.020%, w (S) 0.015%.

4. Cold wire material standards stipulate that w (Ti) 1.75% ~ 2.35%, w (S) 0.40% ~ 1.00%, w (P) 0.025%, w (S) 0.020%

5. The standard for hot-rolled and forged bars stipulates that w (Cu) <025%.

Table 2

Note: Before determining the analysis method for trace elements Se and TeT, actual measured data must be reported and will not be used as the basis for acceptance. Incoloy A-286 heat treatment system

The high-quality Incoloy A-286 heat treatment system is 900C+10C, 1~2h, oil cooling +750+10, 6h, and the IncoloyA-286 heat treatment system specified in the air cooling standard
